The silicon carbide rods
produced by our company have stable quality and complete range of
specifications. There are five categories of rods with more than 300
specifications, including butted type, constant diameter type, trough like type,
saddle-like type, and dual temperature zone type. They are widely used in
different kilns with temperature ranging from 800 to 1, 500 degrees. They can
also be used as the source of infrared rays.
Our products are
extensively used in any field requiring external heating. Some applications of
our products are the heating of ceramic, glass, laboratory equipment, autos,
food service equipment, semiconductors, electronic industries, home appliances
and industrial furnaces and equipment.
We welcome all companies
from at home and abroad to contact us for more details. We are looking forward
to friendly cooperation between us in the near future. If you want to get the
information of products, welcome to visit our website. Tell us what you need, we
will contact you timely.
Order sample:
OD=25mm, HZ=300mm, CZ=200mm, OL=700mm, Resistance=1.2ohms.
Please specify as: dia25x300x700mmx1.2ohms
When you place order, please tell us following data:
a). Outer diameter (OD)
b). Length of Hot zone (HZ)
c). Length of Overall (OL)
d). Resistance (at 1050C +/-50C)
OD=25mm, HZ=300mm, CZ=200mm, OL=700mm, Resistance=1.2ohms.
Please specify as: dia25x300x700mmx1.2ohms
When you place order, please tell us following data:
a). Outer diameter (OD)
b). Length of Hot zone (HZ)
c). Length of Overall (OL)
d). Resistance (at 1050C +/-50C)
| Sic rod specifications and resistance range | |||||||||
| Diameter | Length of hot zone (I) |
Length of cold zone |
Overall Length | Range of Resistance | Diameter |
Length of hot zone (I) |
Length of cold zone |
Overall Length | Range of Resistance |
| (d) | (L) | (d) | (L) | ||||||
| 8 | 100-300 | 60-200 | 240-700 | 2.1-7.2 | 30 | 300-2000 | 250-800 | 800-3600 | 0.4-4.0 |
| 12 | 100-400 | 100-350 | 300-1100 | 0.8-6.0 | 35 | 400-2000 | 250-800 | 900-3600 | 0.5-3.4 |
| 14 | 100-500 | 150-350 | 400-1200 | 0.8-5.6 | 40 | 500-2700 | 250-800 | 1000-4300 | 0.5-3.0 |
| 16 | 200-600 | 200-350 | 600-1300 | 0.8-4.4 | 45 | 500-3000 | 250-750 | 1000-4500 | 0.3-2.5 |
| 18 | 200-800 | 200-400 | 600-1600 | 0.7-5.8 | 50 | 600-2500 | 300-750 | 1200-4000 | 0.3-2.5 |
| 20 | 200-800 | 250-600 | 700-2000 | 0.6-5.0 | 54 | 600-2500 | 300-750 | 1200-4000 | 0.3-2.5 |
| 25 | 200-1200 | 250-700 | 700-2600 | 0.6-4.5 | |||||
